Product Description
UL3304 Fiberglass Braiding Silicone Insulation Electrical Wire
Description
Name: Fiberglass Braiding Silicone Insulation Electrical Wire
Model: UL3304
Size: 24~20AWG
Feature
Ratings Voltage: 10KV
Rated Temperature: 200ºC
Structure
Conductor: Tinned Copper/ Nickel Plated Copper
Insulation: Silicone Rubber
Jacket: Fiberglass Braid with High Temperature Finish
Certifications
Company Information
Packaging&Shipping
FAQ
UL3304 Fiberglass Braiding Silicone Insulation Electrical Wire
Description
Name: Fiberglass Braiding Silicone Insulation Electrical Wire
Model: UL3304
Size: 24~20AWG
Feature
Ratings Voltage: 10KV
Rated Temperature: 200ºC
Structure
Conductor: Tinned Copper/ Nickel Plated Copper
Insulation: Silicone Rubber
Jacket: Fiberglass Braid with High Temperature Finish
| Size (AWG) | Conductor Construction (mm) | Insulation thickness (mm) | Braid Thickness (mm) | Diameter(mm) | Max.Resistance Ω/KM (At 20ºC) |
| 22 | 17/0.16 | >=1.0 | 0.18 | 3.2±0.1 | 59.4 |
| 20 | 26/0.16 | 3.4±0.1 | 37.4 | ||
| 18 | 16/0.254 | 3.6±0.1 | 23.5 | ||
| 16 | 26/0.254 | 4.0±0.1 | 14.6 | ||
| 14 | 41/0.254 | 4.3±0.1 | 8.96 | ||
| 12 | 65/0.254 | 4.9±0.2 | 5.64 |
Certifications
Company Information
Packaging&Shipping
Our Services
1. OEM service available based on official & legal authorization.
2. Strict quality control system.
3. Timely deliverly.
4. Excellent quality with affordable price.
5. Strong technical support.
6. Mobile on 24 hours for any question.
FAQ
1. Why is the price so low?
You are ordering directly from the factory.
2. Where is your factory located? How can I visit there?
Our factory is located in Yangzhou City, Jiangsu Province, China,which is near Shanghai. All our clients, from home or abroad, are warmly welcomed to visit us.
3. Can I get some samples?
Yes, we are honored to offer you samples.
4. Can you make the products with my design?
Yes. customization is welcome .
